Connectors Overview

ASAPIO provides certified, production-ready connectors for all major cloud messaging platforms. Each connector supports outbound (SAP → cloud) and inbound (cloud → SAP) directions, with enterprise-grade security and reliability built in.

Microsoft Azure Amazon AWS Google Cloud Apache Kafka Confluent Solace Platform SAP Adv. Event Mesh Microsoft Fabric

Connector Architecture

All ASAPIO connectors share a common architecture designed for reliability and security in enterprise SAP environments:

• ABAP-native – connectors run as pure ABAP code within the SAP work process. No external runtime, no middleware server, no additional infrastructure.
• Secure credential storage – all credentials (tokens, API keys, passwords, client certificates) are stored in SAP Secure Storage (SSF/PSE), never in Customizing tables or application logs.
• TLS 1.2+ enforced – all connections use TLS 1.2 as a minimum. TLS 1.3 is used when the cloud platform supports it.
• Retry with exponential backoff – configurable retry logic: 3 attempts by default, with delays of 30 seconds, 2 minutes, and 10 minutes. Messages that exhaust all retries are placed in the Dead Letter Queue with full context.
• bgRFC delivery – outbound messages are delivered via SAP's background Remote Function Call framework, ensuring messages are not lost even if the SAP system is restarted during delivery.
• CloudEvents 1.0 – all connectors support CloudEvents 1.0 JSON format by default (configurable per connector).

Authentication Methods

Each connector supports a range of authentication methods. The recommended method for each platform is listed below.

Connector: Azure Service Bus

The Azure Service Bus connector enables reliable messaging between SAP and Azure, supporting queues, topics, and subscriptions with full enterprise messaging semantics including dead-lettering, sessions, and scheduled delivery.

Protocols supported: AMQP 1.0 (recommended for performance) and HTTPS (for restricted network environments). See the full Azure Service Bus connector reference for configuration details.

Connector: Azure Event Hub

Azure Event Hub is designed for high-throughput event streaming. Use it when you need to ingest SAP events at scale (millions per day) into Azure analytics pipelines, Azure Stream Analytics, or Azure Data Lake.

• Event Hub Namespace – the fully qualified namespace name (e.g. mycompany-events.servicebus.windows.net)
• Hub Name – the specific Event Hub within the namespace
• Consumer Group – for inbound: the consumer group to use (default: $Default)
• Partition Key Strategy – how to assign events to partitions: round-robin, SAP SID, or custom field value
• Protocol – AMQP 1.0 (default) or HTTPS

Connector: Apache Kafka / Confluent

The Kafka connector supports both self-hosted Apache Kafka (2.6+) and Confluent Cloud. It provides high-throughput event streaming with exactly-once producer semantics, Avro and JSON Schema support via Confluent Schema Registry, and configurable consumer groups for inbound flows.

See the full Kafka / Confluent connector reference for configuration details, Schema Registry integration, and performance tuning.

Connector: Solace Platform

The Solace connector integrates with Solace Platform (self-hosted and Solace Cloud). It supports AMQP 1.0 and the Solace native SMF protocol, topic subscriptions, and Dead Message Queue (DMQ) configuration.

• Solace Cloud URL – the messaging service URL (e.g. mr-xxxxxx.messaging.solace.cloud)
• VPN Name – the message VPN (e.g. asapio-integration)
• Authentication – Basic (username/password), Client Certificate, or OAuth 2.0
• Topic Subscriptions – wildcard topic subscriptions supported (e.g. sap/s4hana/*/events/>)
• DMQ – configure Dead Message Queue name for messages that cannot be delivered after all retries
• Protocol – AMQP 1.0 (port 5671 TLS) or Solace native AMQP (port 55443)

Connector: SAP Event Mesh

The SAP Event Mesh connector integrates with SAP BTP's managed message broker. It also supports SAP Advanced Event Mesh (AEM), powered by Solace technology, for enterprise-grade mesh topology and cross-region event replication.

See the full SAP Event Mesh connector reference for BTP service key setup, namespace configuration, and AEM-specific options.

Connector: SAP Advanced Event Mesh

SAP Advanced Event Mesh extends Event Mesh with enterprise capabilities: broker links for connecting multiple event brokers, mesh topology for cross-region event replication, and dynamic message routing. AEM is generally available as of ASAPIO v3.2.0.

Configuration is via SAP BTP service key – the AEM service key contains the broker URL, VPN name, and messaging endpoints. Paste the service key JSON into the connector configuration in Event Studio, or map individual fields manually.

Connector: Google Cloud Pub/Sub

The Google Cloud Pub/Sub connector supports both outbound (SAP publishes to a GCP topic) and inbound (SAP subscribes to a GCP subscription). Configuration highlights:

• Service Account JSON – paste the GCP service account key JSON directly into the connector config. ASAPIO stores it in SAP Secure Storage.
• Project ID and Topic/Subscription name – full resource path format: projects/my-project/topics/sap-events
• Message Ordering – enable ordering key support for ordered delivery within a topic partition
• Exactly-Once Delivery – enable for subscriptions that require exactly-once processing (requires GCP exactly-once subscription type)
• Naming Conventions – ASAPIO recommends topic naming: sap-<module>-<event-type>, e.g. sap-mm-goods-movement

Connector: AWS SNS / SQS

The AWS connector supports Amazon SNS (outbound: publish to topic) and Amazon SQS (inbound: poll queue). It also supports the SNS → SQS fan-out pattern common in AWS event-driven architectures.

• Authentication – Access Key + Secret (for dev/test) or IAM Role via STS AssumeRole (recommended for production)
• Region – AWS region (e.g. eu-central-1) – must match your SNS/SQS resource region
• SNS Topic ARN – for outbound: full topic ARN, e.g. arn:aws:sns:eu-central-1:123456789012:sap-events
• SQS Queue URL – for inbound: full queue URL
• FIFO Queue Support – supported; message group ID mapped from a configurable flow field
• Polling Interval – for inbound SQS: configurable from 1 to 300 seconds (default: 30)

Connector: REST API

The generic REST connector allows integration with any HTTP/HTTPS endpoint – external portals, custom APIs, legacy systems, or cloud services not covered by a dedicated connector.

• Outbound – HTTP POST (default) or PUT to a configurable endpoint URL. Supports JSON and XML payloads.
• Inbound – ASAPIO exposes an HTTP endpoint that accepts POST requests. See Inbound Messaging for details.
• Authentication – API Key (custom header name configurable), Basic Auth, OAuth 2.0 Client Credentials flow (token auto-refreshed).
• Headers – configure custom HTTP headers (e.g. X-API-Version: 2, Accept: application/json)
• TLS Client Certificate – mTLS supported; upload the client certificate in STRUST and reference it in the connector config.

Compatibility Matrix
